Conductive PVC Film
Double-Layer Conductive/Insulating PVC Film 1.0 mm
Review the listed specification, test information and intended application before selecting this product.
Product overview
Black double-layer PVC film described in the supplied material notes as a conductive/insulating-layer construction. The supplier workbook reports a surface-resistance value of 100 Ω ±30% for the 1.0 mm variant, citing GB/T 1410. The electrical role of each layer, accessible surface, joining method and required isolation/continuity performance must be defined by the buyer’s drawing and validated on a representative assembly. This listing does not claim an electrical safety class, EMC result, insulation rating or universal chemical resistance.
Key specifications
| Thickness | 1.0 mm |
|---|---|
| Width | Confirm with supplier |
| Length | Confirm with supplier |
| Color | Black |
| Construction | Double-layer conductive/insulating PVC film as described in the supplied material notes |
| Nominal thickness | 1.0 mm (supplier workbook; ±5%) |
| Colour | Black |
| Electrical data | Supplier-reported surface resistance of 100 Ω ±30%; complete test conditions required |
| Roll width and length | Not stated in the supplied conductive-film workbook; confirm at quotation stage |
| Interface design | Buyer must define the conductive side, insulating side, contacts, edge treatment and assembly acceptance method |
Key features
- Conductive/insulating double-layer construction described in supplied material notes
- Supplier-reported surface resistance: 100 Ω ±30%; this must be linked to an agreed test setup
- Variant-specific mechanical data shown only as supplied; no extrapolation to another thickness or construction
- Use a drawing to identify the active surface, contact zones, overlap areas and any required insulation separation
- Request a representative sample and confirm incoming-inspection criteria before series production
Typical applications
- Electronic-device surface connection configurations described in the supplier notes
- Signal or waveguide-related assemblies that have been qualified by the design owner
- Assemblies needing a defined conductive interface and a separately defined insulating side
- Not a claim for geomembrane, waterproofing, food-contact, medical, fire-rated or safety-critical electrical use
Procurement and export planning
- MOQ: Minimum order quantity is confirmed against the material specification, roll dimensions and total order quantity.
- Lead time: Production lead time is confirmed against the selected specification, order scope and requested delivery schedule.
- Packing and container loading: Roll dimensions, destination port and loading requirements should be confirmed before preparing the commercial offer.
- Documents: Identify technical, quality and commercial documents required for the project review.
Request project support
Share your application, required thickness, roll dimensions, quantity and delivery destination for a technical recommendation and quotation.
